Harley-Davidson VRSCDX V-Rod 10th Anniversary 2012 specs
Start the search for your favourite bikes by selecting the make and model and check specs like engine size, suspensions, weight etc.
| Displacement | 1250.08 ccm (76.28 cubic inches) |
| Engine Type | Liquid-cooled, Revolution®, 60° V-Twin |
| Engine Details | V2, four-stroke |
| Torque | 115.26 Nm (11.8 kgf-m or 85.0 ft.lbs) @ 7000 RPM |
| Compression | 11.5:1 |
| Bore X Stroke | 105.0 x 72.0 mm (4.1 x 2.8 inches) |
| Valves Per Cylinder | 4 |
| Fuel System | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Lubrication System | Pressurized, dry-sump |
| Cooling System | Liquid |
| Gearbox | 5-speed |
| Transmission Type Final Drive | Belt |
| Clutch | 9-plate, wet, Assist and Slip |
| Driveline | Primary Drive Gear, 117/64 ratio Final Drive Belt, 72/28 ratio. High-performance carbon-fiber drive belt. |
| Fuel Consumption | 6.36 litres/100 km (15.7 km/l or 36.98 mpg) |
| Greenhouse Gases | 147.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Exhaust System | New Straight-shot exhaust with dual, chrome slash-cut mufflers and chrome exhaust shield |
| Frame Type | Steel perimeter upper frame with hydroformed main rails and bolt-on lower frame rails; MIG welded |
| Front Brakes | Single disc. 4-piston calipers. Optional ABS. |
| Front Brakes Diameter | 300 mm (11.8 inches) |
| Front Suspension | 43 mm Inverted fork |
| Front Tyre | 120/70-ZR19 |
| Front Wheel Travel | 102 mm (4.0 inches) |
| Rake | 34.0° |
| Rear Brakes | Single disc. 4-piston caliper. Optional ABS. |
| Rear Brakes Diameter | 300 mm (11.8 inches) |
| Rear Suspension | Preload adjustable shocks. Polished, one-piece cast aluminum with black powder-coat finish swingarm. |
| Rear Tyre | 240/40-R18 |
| Rear Wheel Travel | 74 mm (2.9 inches) |
| Seat | Two-up seat with custom stitching |
| Trail | 142 mm (5.6 inches) |
| Wheels | Split 5-Spoke Cast Aluminum w/ Machined Highlights |
| Dry Weight | 288.9 kg (637.0 pounds) |
| Fuel Capacity | 18.93 litres (5.00 gallons) |
| Ground Clearance | 122 mm (4.8 inches) |
| Oil Capacity | 4.70 litres (0.31 quarts) |
| Overall Length | 2,365 mm (93.1 inches) |
| Seat Height | 650 mm (25.6 inches) If adjustable, lowest setting. |
| Weight Incl Oil Gas Etc | 303.9 kg (670.0 pounds) |
| Color Options | Brilliant Silver Pearl |
| Electrical | Sealed, maintenance-free battery, 12V, 19-amp/hour, 270 cca |
| Factory Warranty | 2 years, unlimited mileage. |
| Instruments | Electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, tachometer |
