Honda CB 1300 2019 specs

Start the search for your favourite bikes by selecting the make and model and check specs like engine size, suspensions, weight etc.

Displacement 1284.10 ccm (78.36 cubic inches)
Engine Details In-line four, four-stroke
Power 113.98 HP (83.2 kW)) @ 7500 RPM
Torque 117.00 Nm (11.9 kgf-m or 86.3 ft.lbs) @ 5500 RPM
Compression 9.6:1
Bore X Stroke 78.0 x 67.2 mm (3.1 x 2.6 inches)
Valves Per Cylinder 4
Fuel System Injection
Ignition Computer-controlled digital transistorised with electronic advance
Cooling System Liquid
Gearbox 5-speed
Transmission Type Final Drive Chain
Clutch Multidisk
Exhaust System Euro 2/u-Kat

Front Brakes Double disc
Rear Brakes Single disc
Trail 99 mm (3.9 inches)
Front Brakes Diameter 310 mm (12.2 inches)
Front Suspension 43 mm cartridge-type telescopic fork with adjustable compression and rebound damping, 109 mm axle travel
Rear Brakes Diameter 256 mm (10.1 inches)
Rear Suspension Dual conventional dampers with 5-step adjustable spring preload and rebound damping, 116 mm axle travel
Front Tyre 120/70-17
Front Wheel Travel 43 mm (1.7 inches)
Rear Tyre 180/55-17

Dry Weight 224.0 kg (493.8 pounds)
Fuel Capacity 21.00 litres (5.55 gallons)
Ground Clearance 135 mm (5.3 inches)
Power Weight Ratio 0.5088 HP/kg
Seat Height 790 mm (31.1 inches) If adjustable, lowest setting.
Overall Length 2,220 mm (87.4 inches)
Overall Height 1,120 mm (44.1 inches)
Overall Width 790 mm (31.1 inches)

Comments Available with ABS brakes
Starter Electric
