Suzuki GS 500 2006 specs
Start the search for your favourite bikes by selecting the make and model and check specs like engine size, suspensions, weight etc.
| Displacement | 487.00 ccm (29.72 cubic inches) |
| Engine Details | Twin, four-stroke |
| Power | 45.00 HP (32.8 kW)) @ 9000 RPM |
| Torque | 40.00 Nm (4.1 kgf-m or 29.5 ft.lbs) @ 7400 RPM |
| Cooling System | Air |
| Gearbox | 6-speed |
| Valves Per Cylinder | 2 |
| Compression | 9.0:1 |
| Fuel System | Carburettor. Mikuni BST33SS |
| Ignition | CDI |
| Lubrication System | Wet sump |
| Transmission Type Final Drive | Chain |
| Exhaust System | Two-into-one |
| Clutch | Wet multiplate |
| Bore X Stroke | 74.0 x 56.6 mm (2.9 x 2.2 inches) |
| Front Brakes | Single disc |
| Front Tyre | 110/70-17 54H |
| Rear Brakes | Single disc |
| Rear Tyre | 130/70-17 62H |
| Frame Type | Double-cradle frame |
| Front Suspension | Telescopic forks |
| Rear Suspension | Monoshock absorber |
| Dry Weight | 173.0 kg (381.4 pounds) |
| Fuel Capacity | 20.00 litres (5.28 gallons) |
| Ground Clearance | 150 mm (5.9 inches) |
| Overall Height | 1,060 mm (41.7 inches) |
| Overall Length | 2,080 mm (81.9 inches) |
| Overall Width | 800 mm (31.5 inches) |
| Seat Height | 790 mm (31.1 inches) If adjustable, lowest setting. |
| Power Weight Ratio | 0.2663 HP/kg |
| Reserve Fuel Capacity | 3.50 litres (0.92 gallons) |
| Oil Capacity | 2.60 litres (0.17 quarts) |
| Weight Incl Oil Gas Etc | 193.0 kg (425.5 pounds) |
| Starter | Electric |
| Color Options | Red, black |
