Harley-Davidson Sportster Forty-Eight 2020 specs
Start the search for your favourite bikes by selecting the make and model and check specs like engine size, suspensions, weight etc.
| Cooling System | Air |
| Gearbox | 6-speed |
| Transmission Type Final Drive | Belt |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Driveline | 57/38 ratio |
| Fuel Consumption | 4.90 litres/100 km (20.4 km/l or 48.00 mpg) |
| Greenhouse Gases | 113.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Exhaust System | Chrome, staggered shorty exhaust with dual slash-cut mufflers |
| Displacement | 1201.25 ccm (73.30 cubic inches) |
| Engine Type | Air-cooled, Evolution® |
| Engine Details | V2, four-stroke |
| Power | 67.05 HP (48.9 kW)) @ 3750 RPM |
| Torque | 96.00 Nm (9.8 kgf-m or 70.8 ft.lbs) @ 5750 RPM |
| Compression | 9.7:1 |
| Bore X Stroke | 88.9 x 96.8 mm (3.5 x 3.8 inches) |
| Fuel System | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Lubrication System | Dry sump |
| Front Brakes | Single disc. Dual-piston. Optional ABS. |
| Front Suspension | Telescopic fork |
| Front Tyre | 150/80-16 |
| Rake | 29.6° |
| Rear Brakes | Single disc. Single-piston. Optional ABS. |
| Rear Suspension | Twin shocks |
| Rear Tyre | 150/80-B16 |
| Trail | 132 mm (5.2 inches) |
| Wheels | Black, Laced Steel |
| Dry Weight | 247.0 kg (544.5 pounds) |
| Fuel Capacity | 7.90 litres (2.09 gallons) |
| Ground Clearance | 110 mm (4.3 inches) |
| Oil Capacity | 2.60 litres (0.17 quarts) |
| Overall Length | 2,210 mm (87.0 inches) |
| Power Weight Ratio | 0.2715 HP/kg |
| Seat Height | 710 mm (28.0 inches) If adjustable, lowest setting. |
| Weight Incl Oil Gas Etc | 257.0 kg (566.6 pounds) |
| Alternate Seat Height | 711 mm (28.0 inches) If adjustable, highest setting. |
| Color Options | Olive Gold, Velocity Red Sunglo, Hard Candy Cancun Blue Flake, Hard Candy Gold Flake, Vivid Black, Billet Silver |
| Instruments | 4-inch Speedometer mounted low and integrated into handlebar clamp electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, LED indicator lights |
| Light | High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional) |
| Starter | Electric |
