Suzuki AX4 2016 specs
Start the search for your favourite bikes by selecting the make and model and check specs like engine size, suspensions, weight etc.
| Bore X Stroke | 57.0 x 58.6 mm (2.2 x 2.3 inches) |
| Valves Per Cylinder | 2 |
| Fuel System | Carburettor |
| Ignition | CDI |
| Lubrication System | Wet sump |
| Cooling System | Air |
| Gearbox | 5-speed |
| Transmission Type Final Drive | Chain |
| Displacement | 149.5 ccm (9.12 cubic inches) |
| Engine Type | Single cylinder, four-stroke |
| Power | 11.0 HP (8.0 kW)) @ 8000 RPM |
| Torque | 11.5 Nm (1.2 kgf-m or 8.5 ft.lbs) @ 5000 RPM |
| Compression | 11.0:1 |
| Clutch | Wet, multi-disc |
| Engine Details | Single cylinder, four-stroke |
| Front Brakes | Expanding brake (drum brake) |
| Front Suspension | Telescopic, Oil Damped |
| Front Tyre | 2.75-18 |
| Rear Brakes | Expanding brake (drum brake) |
| Rear Suspension | Swing Arm, oil damped |
| Rear Tyre | 90/90-18 |
| Wheels | Cast |
| Fuel Capacity | 12.50 litres (3.30 gallons) |
| Ground Clearance | 165 mm (6.5 inches) |
| Overall Height | 1,075 mm (42.3 inches) |
| Overall Length | 2,055 mm (80.9 inches) |
| Overall Width | 750 mm (29.5 inches) |
| Seat Height | 765 mm (30.1 inches) If adjustable, lowest setting. |
| Weight Incl Oil Gas Etc | 133.0 kg (293.2 pounds) |
| Color Options | Red, black, yellow |
| Comments | Sold in Asia. |
| Starter | Electric & kick |
