Triumph Tiger Explorer XC ABS 2015 specs
Start the search for your favourite bikes by selecting the make and model and check specs like engine size, suspensions, weight etc.
| Displacement | 1215.00 ccm (74.14 cubic inches) |
| Engine Details | In-line three, four-stroke |
| Power | 137.00 HP (100.0 kW)) @ 9300 RPM |
| Torque | 121.00 Nm (12.3 kgf-m or 89.2 ft.lbs) @ 6400 RPM |
| Bore X Stroke | 85.0 x 71.4 mm (3.3 x 2.8 inches) |
| Valves Per Cylinder | 4 |
| Fuel System | Injection. Drive by wire, fuel injection |
| Cooling System | Liquid |
| Gearbox | 6-speed |
| Transmission Type Final Drive | Shaft drive (cardan) |
| Clutch | Wet. multi-plate |
| Fuel Consumption | 4.90 litres/100 km (20.4 km/l or 48.00 mpg) |
| Greenhouse Gases | 113.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Exhaust System | Stainless steel 3 into 1 . side mounted stainless steel silencer |
| Frame Type | Tubular steel Trellis frame |
| Front Brakes | Double disc. Floating discs, Nissin 4-piston calipers, Switchable ABS |
| Front Brakes Diameter | 305 mm (12.0 inches) |
| Front Suspension | Kayaba 46mm upside down forks |
| Front Tyre | 110/80-19 |
| Front Wheel Travel | 190 mm (7.5 inches) |
| Rake | 23.9° |
| Rear Brakes | Single disc. Nissin 2-piston sliding caliper, Switchable ABS |
| Rear Brakes Diameter | 190 mm (7.5 inches) |
| Rear Suspension | Kayaba monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment |
| Rear Tyre | 150/70-17 |
| Rear Wheel Travel | 194 mm (7.6 inches) |
| Trail | 106 mm (4.2 inches) |
| Wheels | Spoked, aluminium rims |
| Dry Weight | 235.5 kg (519.2 pounds) |
| Fuel Capacity | 20.00 litres (5.28 gallons) |
| Oil Capacity | 4.00 litres (0.26 quarts) |
| Overall Height | 1,410 mm (55.5 inches) |
| Overall Length | 2,248 mm (88.5 inches) |
| Overall Width | 885 mm (34.8 inches) |
| Power Weight Ratio | 0.5817 HP/kg |
| Seat Height | 837 mm (33.0 inches) If adjustable, lowest setting. |
| Weight Incl Oil Gas Etc | 265.5 kg (585.3 pounds) |
| Color Options | Graphite, Matt Khaki Green |
| Comments | Windscreen. |
| Factory Warranty | 24 months unlimited mileage |
| Instruments | LCD instrument pack with digital speedometer, analogue tachometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, air temperature, frost warning, hazard warning lights, trip computer, Tyre pressure monitoring system |
| Starter | Electric |
